8400 Full Extension Box or File Drawer Slide
100 lb class full extension drawer slide features an ergonomically designed push-in lever release for easy drawer removal. The reversed flex tabs allow improved slide performance with side clearance tolerance adjustments. 8400 is an unhanded design with traditional 32mm hole pattern that supports industry standards. Recommended maximum drawer width of 24".
Specs
| Finish | Anochrome, Ebony Black, White |
| Sizes | 10", 12", 14", 16", 18", 20", 22", 24", 26", 28", 8" |
| Pack Type | Bulk Pack, Poly Pack |
| Family | 8400 Series Medium-Duty Drawer Slides |
| Brand | KV® |
| Slide Class | Medium-Duty |
| Load Class | 100 lb |
| Slide Width | .50"/12.7mm |
| Slide Height | 1.79"/45.5mm |
| Open Close Features | Hold-In Anti Rebound |
| Base Material | Steel |
| Disconnect | Lever Release |
| Bearing Type | Steel Ball Bearing |
| Load Capacity | 100 lb |
| Product Features |
|
