8405

8405

100 lb. class 1" over travel drawer slide provides additional access to drawer contents. Features an unhanded design and a lever disconnect that allows for easy drawer removal. Recommended for drawers up to 24" wide.

specs

Family
8400
Brand
KV
Slide Class
Medium Duty
Slide Type
Ball Bearing
Load Class
100 lb.
Mounting
Side
Slide Width
.50"/12.7mm
Slide Clearance
.50" +.03" - 0"
Slide Height
1.79"/45.5mm
Slide Extension
Over Travel
Open Close Features
Hold-In Anti Rebound
Material
Steel
Recommended Max Drawer Width
24"
Disconnect
Lever Release
Bearing Type
Steel Ball Bearing

Available options

Item (Click for detail & option to buy) Length Finish Pack Carton Quantity Unit of Measure Order Quantity Price per Order Quantity
8405B 10 10" Anochrome Bulk 10 PAIR FULL CARTON $216.50
8405B 12 12" Anochrome Bulk 10 PAIR FULL CARTON $221.80
8405B 14 14" Anochrome Bulk 10 PAIR FULL CARTON $228.00
8405B 16 16" Anochrome Bulk 10 PAIR FULL CARTON $235.80
8405B 18 18" Anochrome Bulk 10 PAIR FULL CARTON $244.30
8405B 20 20" Anochrome Bulk 10 PAIR FULL CARTON $253.00
8405B 22 22" Anochrome Bulk 10 PAIR FULL CARTON $262.30
8405B 24 24" Anochrome Bulk 10 PAIR FULL CARTON $271.00
8405B 26 26" Anochrome Bulk 10 PAIR FULL CARTON $281.30
8405B 28 28" Anochrome Bulk 10 PAIR FULL CARTON $291.30
8405B EB 10 10" Ebony Black Bulk 10 PAIR FULL CARTON $228.00
8405B EB 12 12" Ebony Black Bulk 10 PAIR FULL CARTON $233.80
8405B EB 14 14" Ebony Black Bulk 10 PAIR FULL CARTON $239.30
8405B EB 16 16" Ebony Black Bulk 10 PAIR FULL CARTON $248.00
8405B EB 18 18" Ebony Black Bulk 10 PAIR FULL CARTON $256.80
8405B EB 20 20" Ebony Black Bulk 10 PAIR FULL CARTON $265.30
8405B EB 22 22" Ebony Black Bulk 10 PAIR FULL CARTON $275.00
8405B EB 24 24" Ebony Black Bulk 10 PAIR FULL CARTON $284.80
8405P 10 10" Anochrome Poly Bag 10 PAIR PAIR $24.28
8405P 12 12" Anochrome Poly Bag 10 PAIR PAIR $24.43
8405P 14 14" Anochrome Poly Bag 10 PAIR PAIR $25.10
8405P 16 16" Anochrome Poly Bag 10 PAIR PAIR $25.93
8405P 18 18" Anochrome Poly Bag 10 PAIR PAIR $26.78
8405P 20 20" Anochrome Poly Bag 10 PAIR PAIR $27.58
8405P 22 22" Anochrome Poly Bag 10 PAIR PAIR $28.53
8405P 24 24" Anochrome Poly Bag 10 PAIR PAIR $29.53
8405P 26 26" Anochrome Poly Bag 10 PAIR PAIR $30.45
8405P 28 28" Anochrome Poly Bag 10 PAIR PAIR $31.88
